RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    Buy cheap RK3288 477.8mmx269.3mm Open Frame Lcd Monitor from wholesalers

    Buy cheap RK3288 477.8mmx269.3mm Open Frame Lcd Monitor from wholesalers
    • Buy cheap RK3288 477.8mmx269.3mm Open Frame Lcd Monitor from wholesalers

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    Ask Lasest Price
    Brand Name : TouchDisplays
    Model Number : 2151E-IOT
    Certification : CE/FCC/RoHS
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 2000 units per month
    • Product Details
    • Company Profile

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    INDOOR HD OPEN FRAME MONITOR LCD TOUCH DISPLAY TOUCH SCREEN MONITOR


    TouchDisplays open frame LCD touch screen display, featured with slim body and powerful projected capacitive multi touch screen. Our open frame touch screen brings you really quick and accurate touch response and reliable and durable quality. And we devote ourselves to satisfy all customization requirements, make the touch screens easily meet any application for Casino, Kiosk, Education, Self-services, Industrial automation, Entertainment and Advertising.

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    LEADING TOUCH


    TouchDisplays use the proven industry-leading touch technology. We offer projected capacitive (PACP) 10 points multi-touch, 5-wire resistive single touch and Infrared (IR) 10 points multi-touch, to meet with different applications.


    TouchDisplays Open-frame Touch monitor with vivid color, and utmost reliable quality give visually striking for customer. This powerful open-frame capacitive touch optional display is ideal for systems integrate and OEM, allowing owners to win in all kind areas.

    Customizing is what TouchDisplays lives on. Any parameter of our screens would be customizable for you, thickness, resolution, brightness, viewing angle and color; you can always find the one you need.

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor
    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    Compatible VESA mount 75*75/ 100*100 for both wall mounting and kiosk built-in.

    VAG, HDMI and DVI interfaces to meet your requirements and best performance.

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    RELIABILITY AND WARRANTY


    For all time, TouchDisplays try our best to supply touch screens with the best quality, and 3-year standard warranty is always our base line. We focus on providing reassuring devices for any customer, very single screen will be tested before delivery.

    PERIPHERALS- TOUCHDISPLAYS COMPUTER BACKUPS


    For your touch screen displays, TouchDisplays offers rugged industrial single board computer backups, with customizable configurations and dimension. Which is a Windows/Android based platform with high expansion capability.

    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    APPLICATION


    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor


    DRAWINGS


    RK3288 477.8mmx269.3mm Open Frame Lcd Monitor

    SPECIFICATION


    Model2151E-OT-F
    Case/Bezel ColorBlackwhite
    Display Size21.5"
    Touch panelProjected Capacitive Touch Screen
    Touch points10
    Touch response time8ms
    Touchmonitors Dimensions524 x 45.8 x 315.5 mm
    LCD TypeTFT LCD(LED backlight)
    Useful Screen Area477.8 mm x 269.3 mm
    Aspect ratio16:9
    Optimal (native) Resolution1920*1080
    LCD panel Pixel pitch0.1875 x 0.1875 mm
    LCD panel Colors16.7 million
    LCD panel Brightness250 cd/m2(customized upto 1000 cd/m2 optional)
    LCD panel Response Time25 ms

    Viewing Angle

    (typical, from center)

    Horizontal±89° or 178° total
    Vertical±89° or 178° total
    Contrast Ratio3000:1
    Input Video signal connectorMini D-Sub 15-Pin VGA type and HDMI type or DVI type optional
    Input Touch signal connectorUSB or COM (optional)
    Power Supply TypeMonitor input interface: +12VDC ±5%,4.0 A; DC Jack (2.5¢)
    AC to DC power brick input: 100-240 VAC, 50/60 Hz
    Power Consumption: 30W
    On-screen display(OSD)

    Controls(back): PowerMenuUpDownAuto;

    Settings: Contrast, Brightness, H/V position;

    RGB(color temp),Clock, Phase, Recall;

    Languages: English, German, French ,Spanish, Japanese, Italy, Chinese;

    TemperatureOperating: 0°C to 40°C ;Storage -20°C to 60°C
    Humidity (non-condensing)Operating: 20%-80%; Storage: 10%-90%
    Shipping Carton Dimensions616 x 206 x 456 mm (2 PCS)
    Weight (approx.)Actual: 5.8 kg ;Shipping: 14.2 kg(2 PCS)
    Warranty Monitor3 years(Except for LCD panel 1 year)
    Backlight lamp life: typical 50,000 hours to half brightness
    Agency ApprovalsCE FCC RoHS (UL or GS for Customized)
    Mounting Options75 mm and 100 mm VESA mount
