    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    Ask Lasest Price
    Brand Name : TouchDisplays
    Model Number : 2151E-IOT
    Certification : CE/FCC/RoHS
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 2000 units per month
    • Product Details
    • Company Profile

    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    CE Certified 21.5 Inch Open Frame Touch Screen Monitor 250cd/m2

    The 21.5-inch touch monitor is a specialized product solution that mainly purposes to solve the demand for customized products. With custom thickness, it offers a commercial-grade product. Projection multi-touch and VESA mounting enable it to meet a multi-purpose, tempered glass design that can withstand extreme operating environments. Moreover, based on the durability design of the screen, IP 65 standard front screen splash proof and dust proof allows it to fit most environments.

    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    TEN POINTS TOUCH FUNCTION


    The multi-touch function is supported by this superior PCAP touch screen which creates an excellent experience of regular use.



    Customizing is what TouchDisplays lives on. Support full customization, appearance like color, dimension, function dimension like anti-explosion, module customization like MIC. You can always find the unique one you need.


    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2
    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    Compatible VESA mount 75*75/ 100*100 for both wall mounting and kiosk built-in.


    Multiple VAG, HDMI and DVI interfaces to meet your requirements and best performance.

    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    WARRANTY & SPARE PARTS CONDITIONS


    (1). 3-Year standard warranty guarantee.


    (2). Provide high-end quality for customers to enjoy a better experience.


    (3). Support the best product to earn stable relationships and belief.


    (4). Offer original authentic products to customers.


    (5). 100% environment-friendly products.

    PERIPHERALS- TOUCHDISPLAYS COMPUTER BACKUPS


    For your touch screen displays, TouchDisplays provides a rugged industrial single-board computer backup, with customizable configurations and dimensions. This is a platform with high scalability based on Windows/Android.

    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    APPLICATION


    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2


    DRAWINGS


    CE Certified Open Frame Touch Screen Monitor 21.5 Inch 250cd/m2

    SPECIFICATION


    Model2151E-OT-F
    Case/Bezel ColorBlackwhite
    Display Size21.5"
    Touch panelProjected Capacitive Touch Screen
    Touch points10
    Touch response time8ms
    Touchmonitors Dimensions524 x 45.8 x 315.5 mm
    LCD TypeTFT LCD(LED backlight)
    Useful Screen Area477.8 mm x 269.3 mm
    Aspect ratio16:9
    Optimal (native) Resolution1920*1080
    LCD panel Pixel pitch0.1875 x 0.1875 mm
    LCD panel Colors16.7 million
    LCD panel Brightness250 cd/m2(customized upto 1000 cd/m2 optional)
    LCD panel Response Time25 ms

    Viewing Angle

    (typical, from center)

    Horizontal±89° or 178° total
    Vertical±89° or 178° total
    Contrast Ratio3000:1
    Input Video signal connectorMini D-Sub 15-Pin VGA type and HDMI type or DVI type optional
    Input Touch signal connectorUSB or COM (optional)
    Power Supply TypeMonitor input interface: +12VDC ±5%,4.0 A; DC Jack (2.5)
    AC to DC power brick input: 100-240 VAC, 50/60 Hz
    Power Consumption: 30W
    On-screen display(OSD)

    Controls(back): PowerMenuUpDownAuto;

    Settings: Contrast, Brightness, H/V position;

    RGB(color temp),Clock, Phase, Recall;

    Languages: English, German, French ,Spanish, Japanese, Italy, Chinese;

    TemperatureOperating: 0°C to 40°C ;Storage -20°C to 60°C
    Humidity (non-condensing)Operating: 20%-80%; Storage: 10%-90%
    Shipping Carton Dimensions616 x 206 x 456 mm (2 PCS)
    Weight (approx.)Actual: 5.8 kg ;Shipping: 14.2 kg(2 PCS)
    Warranty Monitor3 years(Except for LCD panel 1 year)
    Backlight lamp life: typical 50,000 hours to half brightness
    Agency ApprovalsCE FCC RoHS (UL or GS for Customized)
    Mounting Options75 mm and 100 mm VESA mount
