Intel I5 TFT LCD Interactive Touch Screen Whiteboard

    Buy cheap Intel I5 TFT LCD Interactive Touch Screen Whiteboard from wholesalers

    Buy cheap Intel I5 TFT LCD Interactive Touch Screen Whiteboard from wholesalers
    • Buy cheap Intel I5 TFT LCD Interactive Touch Screen Whiteboard from wholesalers

    Intel I5 TFT LCD Interactive Touch Screen Whiteboard

    Ask Lasest Price
    Brand Name : TouchDisplays
    Model Number : 6501E-IDT
    Certification : CE/FCC RoHS (UL & GS customized)
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 2000 units per month
    • Product Details
    • Company Profile

    Intel I5 TFT LCD Interactive Touch Screen Whiteboard

    65 inch smart display electronic whiteboard digital smart interactive whiteboard


    An interactive whiteboard (IWB) also commonly known as Interactive board or Smart boards is a large interactive display in the form factor of a whiteboard. It can either be a standalone touchscreen computer used independently to perform tasks and operations, or a connectable apparatus used as a touchpad to control computers from a projector. They are used in a variety of settings, including classrooms at all levels of education, in corporate board rooms and work groups, in training rooms for professional sports coaching, in broadcasting studios, and others.

    SMART INTERACTIVE WHITEBOARD


    Used for

    Early childhood education

    School teaching

    Training institutions

    Scientific research and ect


    MULTI FUNCTION


    lntegrated computer/playback box/projector/projection screen/ electronic whiteboard and all in one


    Intel I5 TFT LCD Interactive Touch Screen Whiteboard

    COMPLETE CONFIGURATION AND STABLE FUNCTION


    Equipped with a safe and stable processor, Android/i3/i5/i7 optional



    APPLICATIONS

    SMOOTH WRITING,MULTI-TOUCH
    support 20-point touch, High Sensitivity,Fast Response

    Intel I5 TFT LCD Interactive Touch Screen Whiteboard


    SPECIFICATION

    Model6501E-IOT
    Case/Bezel ColorBlack/Silvery/white(Customized)
    Display Size65″
    Touch panelIR touch screen
    Touch response time16ms
    Touchcomputors Dimensions1483 mm*80.4 mm*858 mm
    LCD TypeTFT LCD(LED backlight)
    Useful Screen Area1428.48 mm x 803.52 mm
    Aspect ratio16 : 9
    Optimal (native) Resolution1920 x 1080 (4K resolution optional)
    LCD panel Pixel pitch0.248 x 0.744 mm
    LCD panel Colors1.07G colors (8-bit+FRC)
    LCD panel Brightness350 cd/m2(customized upto 1000-2000 cd/m2 optional)
    LCD panel Response Time6.5 ms
    LCD panel Contrast Ratio5000:1
    Viewing AngleHorizontal±89° or 178° total
    (typical, from center)Vertical±89° or 178° total
    Monitor modulinput interfaceVGA(for computor display input)DVIHDMI(for another display input)
    Earphone out*1Audio in*1
    Computer modulInput interfaceUSB 2.0*4(USB 3.0*1 optional)PCI-E(4G SIM card, WIFI and Bluetooth optional)
    output interfaceEarphone*1Mic*1Com*3RJ45*1
    VGA(for computor display output) and HDMI(for second display output)
    Extend interfaceUSB2.0*4Com*21*PLTSATA3.0
    ECM (Embed Computer Modul)

    ECM4: Intel® processor i3 5010U (Dual Core 2.1GH, Fanless);
    ECM5: Intel® processor i5 5200U (Dual Core 2.2GHz/2.7GHz Turbo, Fanless);
    ECM6: Intel® processor i7 5500U (Dual Core 2.4GHz/3.0GHz Turbo, Fanless);
    HDD:500G(1TB optional) or SDD:32G(up to 128G optional);
    Memory: DDR3 4G(up to 16G);
    CPU Upgrade: I3-I7 series 6th 7th optional
    Operation System:Win7Pos ready7Win8XPWinCEVistaLinux Ubuntu

    Power Supply TypeAC to DC power brick input: 90-240 VAC, 50/60 Hz
    Power Consumption: 90W
    TemperatureOperating: 0°C to 40°C ;Storage -20°C to 60°C
    Humidity (non condensing)Operating: 20%-80%; Storage: 10%-90%
    Shipping Carton Dimensions1600 x 240 x 1000 mm (2 PCS)
    Weight (approx.)Product Actual: 41 kg (1 piece) ; Shipping: 99 kg ( 2 PCS )
    Warranty Monitor4 years(Except for LCD panel 1 year)
    Backlight lamp life: typical 30,000 hours to half brightness
    Agency ApprovalsCE/FCC RoHS(UL GS optional)
    Mounting Options200mmx100mm VESA mount
