Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    Buy cheap Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor from wholesalers

    Buy cheap Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor from wholesalers
    • Buy cheap Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor from wholesalers

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    Ask Lasest Price
    Brand Name : TouchDisplays
    Model Number : 2151E-IOT
    Certification : FCC/ CE/ RoHS
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 2000 units per month
    • Product Details
    • Company Profile

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    21.5 Inch Core I7 1080p All-In-One 64g Ddr3 Wall Mount Touch Screen Cheap All In One Pc


    Our Touch Screen Monitor allows users to manipulate a host computer by gently touching ICONS or text on the Screen with their fingers, eliminating keyboard and mouse manipulation and making human-computer interaction more straightforward.Mainly used in public hall information query, leadership office, video games, song ordering, multimedia teaching, air/train ticket booking, etc.

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    PRECISE TOUCH AND SENSITIVE

    Using the original touch screen, 10 touch points , sensitive response, no jumping point, high stability, bring a smooth touch experience.


    HIGH PROTECTION LEVEL FOR FRONT FRAME IP64

    With IP64 high protection grade, meet the IEC seal specification, can work normally in the environment of dust and humidity, super protection, reliable and durable, can operate in all kinds of harsh industrial environment.



    -20C-60C working temperature, users can operate through IP64 dustproof and water-proof high resistance touch screen, compact appearance, easy to install, can be perfect for man-machine interaction application in industrial environment.

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor
    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    FEATURES


    1.Unique capacitance technology with the stable and sensitive touch feel


    2.High brightness and contrast, Fast response time, Multi-color support and the wide viewing angle


    3.Touch and display LCD integrated solution


    4.Finger touch operation smoothly


    5.USB touchscreen interface


    6.VGA/HD-MI video input format

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    FEATURES


    1, TFT lcd screen Grade A;


    2, Capacitive 10 points touch;


    3, 8ms high response speed;


    4, Various interfaces are available, USB, VGA, RJ45, etc.


    5, Unibody aluminium housing for better outlook and longer lifepan;


    6, Multiple mounting options: VESA mount,horizontal or vertical bracket-mount;


    7, OEM/ODM serive support;


    8, Embedded front frame design.

    PERIPHERALS- TOUCHDISPLAYS COMPUTER BACKUPS


    For your touch screen displays, TouchDisplays offers rugged industrial single board computer backups, with customizable configurations and dimension. Which is a Windows/Android based platform with high expansion capability.

    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    APPLICATION


    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor


    DRAWINGS


    Intel Core I7 1080P 64G SSD Wall Mounted Touch Screen Monitor

    SPECIFICATION


    Model2151E-OT-F
    Case/Bezel ColorBlackwhite
    Display Size21.5"
    Touch panelProjected Capacitive Touch Screen
    Touch points10
    Touch response time8ms
    Touchmonitors Dimensions524 x 45.8 x 315.5 mm
    LCD TypeTFT LCD(LED backlight)
    Useful Screen Area477.8 mm x 269.3 mm
    Aspect ratio16:9
    Optimal (native) Resolution1920*1080
    LCD panel Pixel pitch0.1875 x 0.1875 mm
    LCD panel Colors16.7 million
    LCD panel Brightness250 cd/m2(customized upto 1000 cd/m2 optional)
    LCD panel Response Time25 ms

    Viewing Angle

    (typical, from center)

    Horizontal±89° or 178° total
    Vertical±89° or 178° total
    Contrast Ratio3000:1
    Input Video signal connectorMini D-Sub 15-Pin VGA type and HDMI type or DVI type optional
    Input Touch signal connectorUSB or COM (optional)
    Power Supply TypeMonitor input interface: +12VDC ±5%,4.0 A; DC Jack (2.5¢)
    AC to DC power brick input: 100-240 VAC, 50/60 Hz
    Power Consumption: 30W
    On-screen display(OSD)

    Controls(back): PowerMenuUpDownAuto;

    Settings: Contrast, Brightness, H/V position;

    RGB(color temp),Clock, Phase, Recall;

    Languages: English, German, French ,Spanish, Japanese, Italy, Chinese;

    TemperatureOperating: 0°C to 40°C ;Storage -20°C to 60°C
    Humidity (non-condensing)Operating: 20%-80%; Storage: 10%-90%
    Shipping Carton Dimensions616 x 206 x 456 mm (2 PCS)
    Weight (approx.)Actual: 5.8 kg ;Shipping: 14.2 kg(2 PCS)
    Warranty Monitor3 years(Except for LCD panel 1 year)
    Backlight lamp life: typical 50,000 hours to half brightness
    Agency ApprovalsCE FCC RoHS (UL or GS for Customized)
    Mounting Options75 mm and 100 mm VESA mount
